The "Macro" is suitable for precision mechanical parts processing in almost all industrial sectors. It delivers cost-effective, excellent results for machining requiring precise profiling, grooving or strict surface finish.In the aero-engine and stationary steam turbine industries, it can effectively grind parts with poor machinability, such as turbine blades. It is also applicable to linear guideway assemblies, serrated surfaces, racks, gear rings, guideways, fixtures, cutting tools, broaches and high-precision ceramic workpieces.Additionally, it is used for steering system parts and rocker arms in the automotive industry, as well as stator and rotor machining in the hydraulic industry.

The "Macro-S" is specifically designed for cellular manufacturing installations, with an overall width of only 1500mm (59.055""). For production lines, its custom coolant discharge and operation platform offer high flexibility, allowing free rearrangement. Thus, it is ideal for multi-machine setups and assembly line production, easily adapting to production process changes. Despite its compact size, it delivers high-efficiency grinding, on par with our larger high-production machine models.

The "Macro" series adopts the innovative Moving-Wheel-Head (MWH) concept. All linear movements during positioning and precision grinding are achieved by the grinding head. The "Macro" is suitable for precision mechanical parts processing in almost all industrial fields. It delivers cost-effective, excellent results for machining requiring precise profiling, grooving or strict surface roughness.

Torque Tube Design
Resin Concrete-Filled Bed
Grinding Head Slide Carriage (Cast Iron)
Excellent Shock Absorption
High Thermal Stability
Circulating Water Cooling for Spindle & Drive Shaft
Multiple Grinding Wheel Speeds & Power Ratings
Stable Temperature During Grinding
Consistently Produces High-Quality Parts

Software Features
State-of-the-Art CNC Technology: Siemens 840D System, Multi-Channel, Up to 5-Axis Interpolation Control
Pre-Installed Programs & Grinding Cycles
Optional: Acoustic Emission Monitoring System – Sensor at spindle front, with induced signals transmitted back.
Options: Integrated Grinding Wheel Balancing System, High-Pressure Cleaner, Automatic Nozzle Adjustment, etc.

Software Advantages
Easy to Operate – Ideal for Complex Grinding
User-Friendly, Suitable for Various Grinding Processes
Workpiece Collision Monitoring – Preliminary Inspection & Dressing, Enhancing Safety & Reducing Costs
Tailor-Made to Customer Needs
