The equipment adopts a heavy-duty shockproof structural steel vertical housing design, featuring 4 integrally installed 2kW (1.5HP) polishing spindles. The buff diameter is 300mm, with a speed range of 300-3,000rpm.
Equipped with two independent 5-axis (X, Y, Z, X2, and C-axis) actuator systems, each axis is fitted with a closed-loop servo motor to provide flexible and reliable movement. Encoders can feed back accurate position, speed, and acceleration. Precision ball screws used on each axis deliver linear motion with minimal friction.
The force feedback system uses an independent X-axis (X2) and PID loop control to ensure constant pressure exerted by the polishing disc on the workpiece. The equipment body is protected against dust by an aluminum frame shield and lower stainless steel coaming.
It is equipped with a combustible dust management system, including an automatic workpiece humidification function, and an automatic lubrication system for linear guides that are prone to contamination.
Additional configurations include a high-pressure liquid polishing wax spray system, an electronic metering device, independent polishing wax buckets capable of supplying 4 spray guns, interlocked safety doors, 4 quick-disconnect mechanical chuck-type fixtures, and a 380V/50Hz circuit system.

Four independent 5-axis CNC servo motor control systems, capable of processing four workpiece areas simultaneously.
The precise ball screws for X, Y, Z, and X2, as well as the precise rotating actuators on the C-axis, perform linear and rotational movements, generating minimal friction.
Closed-loop encoders that accurately feedback position, speed, and acceleration.
A force feedback system, using an independent X-axis (X2) and PID loop control, ensures that the polishing disc applies a constant pressure to the workpiece.
The equipment body is protected by an aluminum frame guard and a lower stainless steel panel for dust prevention.
The high-pressure spray system for liquid polishing wax, along with the electronic metering and pumping system, can provide the required amount for 20 devices through the central polishing wax bucket.
Flammable dust management system, including an automatic workpiece humidification function.
Automatically adjust the polishing spindle speed based on the wear of the wheels to maintain a continuous cutting rate (SFM).
A quick-release mechanical chuck fixture (4) for fixing the workpiece during processing.
An automatic lubrication system (linear guide rail).
The C-axis for rotating multiple polishing wheels.
The equipment is designed in a fully enclosed manner, with a safety door featuring interlocking functionality.
Electrodeless cold air guns for cooling the polishing wax on SUS equipment.
Special dust control measures.
